Jetson Module
AGX Orin
AGX Orin
AGX Orin
AGX Orin
AGX Orin
Memory / RAM
32GB RAM
32GB RAM
64GB RAM
64GB RAM
64GB RAM
Storage
64GB internal eMMC 5.1
64GB internal eMMC 5.1
64GB internal eMMC 5.1
64GB internal eMMC 5.1
64GB internal eMMC 5.1
Display out
1x Displayport 1.4a
1x Displayport 1.4a
1x Displayport 1.4a
1x Displayport 1.4a
1x Displayport 1.4a
USB
1x USB 3.1 (Type-A)
2x USB 2.0 (Type-A, behind cover)
1x USB 2.0 (micro AB, behind cover)
1x USB 3.1 (Type-A)
2x USB 2.0 (Type-A, behind cover)
1x USB 2.0 (micro AB, behind cover)
1x USB 3.1 (Type-A)
2x USB 2.0 (Type-A, behind cover)
1x USB 2.0 (micro AB, behind cover)
1x USB 3.1 (Type-A)
2x USB 2.0 (Type-A, behind cover)
1x USB 2.0 (micro AB, behind cover)
1x USB 3.1 (Type-A)
2x USB 2.0 (Type-A, behind cover)
1x USB 2.0 (micro AB, behind cover)
Networking
1x 10/100/1000/10'000 BASE-T
1x 10/100/1000BASE-T
1x 10/100/1000/10'000 BASE-T
1x 10/100/1000BASE-T
1x 10/100/1000/10'000 BASE-T
1x 10/100/1000BASE-T
1x 10/100/1000/10'000 BASE-T
1x 10/100/1000BASE-T
1x 10/100/1000/10'000 BASE-T
1x 10/100/1000BASE-T
CAN
2x CAN2.0A / CAN2.0B with CAN-FD support
2x CAN2.0A / CAN2.0B with CAN-FD support
2x CAN2.0A / CAN2.0B with CAN-FD support
2x CAN2.0A / CAN2.0B with CAN-FD support
2x CAN2.0A / CAN2.0B with CAN-FD support
Serial
1x RS 232
1x RS 232
1x RS 232
1x RS 232
1x RS 232
Digital I/O
4in / 2out
4in / 2out
4in / 2out
4in / 2out
4in / 2out
Wireless
4G LTE w/GNSS
Wi-Fi 6E ax/ac/a/b/g/n & Bluetooth 5.2
-
4G LTE w/GNSS
Wi-Fi 6E ax/ac/a/b/g/n & Bluetooth 5.2
-
Cellular 5G
Wi-Fi 6E & BT 5.2
RTK GNSS w/heading
Expansion slots
1x M.2 3042 (Key B) > LTE
1x M.2 2230 (Key E) > Wi-Fi
1x M.2 2280 (Key M) > SSD storage
1x M.2 3042 (Key B)
1x M.2 2230 (Key E)
1x M.2 2280 (Key M) > SSD storage
1x M.2 3042 (Key B) > LTE
1x M.2 2230 (Key E) > Wi-Fi
1x M.2 2280 (Key M) > SSD storage
1x M.2 3042 (Key B)
1x M.2 2230 (Key E)
1x M.2 2280 (Key M) > SSD storage
1x M.2 3042 (Key B) > 5G
1x M.2 2230 (Key E) > Wi-Fi
1x M.2 2280 (Key M) > used for SSD storage
Power Input
9.5-45V DC Power input
9.5-45V DC Power input
9.5-45V DC Power input
9.5-45V DC Power input
9.5-45V DC Power input
Protection class
IP67, IP69K
IP67, IP69K
IP67, IP69K
IP67, IP69K
IP67, IP69K
Dimensions
w250 x h100 x d170
w250 x h100 x d170
w250 x h100 x d170
w250 x h100 x d170
w250 x h100 x d170
Weight
4.25kg
4.2kg
4.25kg
4.2kg
4.3kg
Op. Temp. range
-25°C to +70°C
-25°C to +70°C
-25°C to +70°C
-25°C to +70°C
-25°C to +70°C
